YB3 series Explosion-Proof Three-Phase Induction Motor
+
  • YB3 series Explosion-Proof Three-Phase Induction Motor

  PERFORMANCE DATA                                            380V  50Hz

Type Power
kW
Current
A
Speed
r/min
Eff
%
Power factor Locked rotor torque
Rated torque
Locked rotor current
Rated current
Breakdown torque
Rated torque
Synchronous speed   3000r/min
YB3-63M1-2 0.18 0.53 2720 65.9 0.80 2.3 7.0 2.2
YB3-63M2-2 0.25 0.69 2720 69.7 0.81 2.3 7.0 2.2
YB3-71M1-2 0.37 0.99 2740 73.8 0.81 2.3 7.0 2.2
YB3-71M2-2 0.55 1.4 2740 77.8 0.82 2.3 7.0 2.2
YB3-80M1-2 0.75 1.8 2840 80.7 0.82 2.3 7.0 2.3
YB3-80M2-2 1.1 2.6 2840 82.7 0.83 2.3 7.6 2.3
YB3-90S-2 1.5 3.4 2845 84.2 0.84 2.2 7.9 2.3
YB3-90L-2 2.2 4.9 2845 85.9 0.85 2.2 7.9 2.3
YB3-100L-2 3 6.3 2860 87.1 0.87 2.2 8.5 2.3
YB3-112M-2 4 8.1 2880 88.1 0.88 2.2 8.5 2.3
YB3-132S1-2 5.5 11.0 2900 89.2 0.88 2.0 8.5 2.3
YB3-132S2-2 7.5 14.9 2900 90.1 0.88 2.0 8.5 2.3
YB3-160M1-2 11 21.3 2930 91.2 0.89 2.0 8.5 2.3
YB3-160M2-2 15 28.8 2930 91.9 0.89 2.0 8.5 2.3
YB3-160L-2 18.5 34.7 2930 92.4 0.89 2.0 8.5 2.3
YB3-180M-2 22 41.0 2940 92.7 0.89 2.0 8.5 2.3
YB3-200L1-2 30 55.5 2940 93.3 0.89 2.0 8.5 2.3
YB3-200L2-2 37 67.9 2950 93.7 0.90 2.0 8.5 2.3
YB3-225M-2 45 82.3 2960 94.0 0.90 2.0 8.0 2.3
YB3-250M-2 55 100 2965 94.3 0.90 2.0 8.0 2.3
YB3-280S-2 75 135 2970 94.7 0.90 2.0 7.5 2.3
YB3-280M-2 90 160 2970 95.0 0.91 1.8 7.5 2.3
YB3-315S-2 110 195 2975 95.2 0.91 1.8 7.5 2.3
YB3-315M-2 132 233 2975 95.4 0.91 1.8 7.5 2.3
YB3-315L1-2 160 279 2975 95.6 0.91 1.8 7.5 2.3
YB3-315L2-2 200 348 2975 95.8 0.92 1.8 7.5 2.3
YB3-355M-2 250 433 2980 95.8 0.92 1.8 7.5 2.2
YB3-355L-2 315 544 2980 95.8 0.92 1.6 7.5 2.2
Synchronous speed    1500r/min
YB3-63M1-4 0.12 0.44 1310 64.8 0.73 2.1 6.6 2.2
YB3-63M2-4 0.18 0.62 1310 69.9 0.74 2.1 6.6 2.2
YB3-71M1-4 0.25 0.79 1330 73.5 0.75 2.1 6.6 2.2
YB3-71M2-4 0.37 1.12 1330 77.3 0.75 2.1 6.6 2.2
YB3-80M1-4 0.55 1.6 1390 80.8 0.75 2.4 6.6 2.3
YB3-80M2-4 0.75 2 1390 82.5 0.76 2.3 6.6 2.3
YB3-90S-4 1.1 2.9 1400 84.1 0.77 2.3 6.8 2.3
YB3-90L-4 1.5 3.7 1400 85.3 0.81 2.3 7.0 2.3
YB3-100L1-4 2.2 5.2 1420 86.7 0.82 2.3 7.6 2.3
YB3-100L2-4 3 6.8 1420 87.7 0.82 2.3 7.7 2.3
YB3-112M-4 4 8.8 1440 88.6 0.83 2.2 7.8 2.3
YB3-132S-4 5.5 11.8 1440 89.6 0.84 2.0 7.9 2.3
YB3-132M-4 7.5 15.6 1440 90.4 0.86 2.0 7.7 2.3
YB3-160M-4 11 22.3 1460 91.4 0.86 2.0 7 2.3
YB3-160L-4 15 30.1 1460 92.1 0.86 2.0 7.8 2.3
YB3-180M-4 18.5 36.1 1470 92.6 0.86 2.0 7.9 2.3
YB3-180L-4 22 42.7 1470 93.0 0.86 2.0 7.5 2.3
YB3-200L-4 30 57.6 1470 93.6 0.86 2.0 7.7 2.3
YB3-225S-4 37 69.9 1475 93.9 0.88 2.0 7.8 2.3
YB3-225M-4 45 84.7 1475 94.2 0.89 2.0 7.8 2.3
YB3-250M-4 55 103 1480 94.6 0.89 2.2 7.8 2.3
YB3-280S-4 75 140 1480 95.0 0.89 2.0 7.3 2.3
YB3-280M-4 90 167 1480 95.2 0.90 2.0 7.4 2.3
YB3-315S-4 110 201 1480 95.4 0.90 2.0 7.4 2.3
YB3-315M-4 132 240 1480 95.6 0.90 2.0 7.4 2.3
YB3-315L1-4 160 288 1480 95.8 0.89 2.0 6.9 2.3
YB3-315L2-4 200 356 1480 96.0 0.89 2.0 6.9 2.2
YB3-355M-4 250 442 1490 96.0 0.90 2.0 7.1 2.2
YB3-355L-4 315 556 1490 96.0 0.87 2.0 7.1 2.2
Type Power
kW
Current
A
Speed
r/min
Eff
%
Power factor Locked rotor torque
Rated torque
Locked rotor current
Rated current
Breakdown torque
Rated torque
Synchronous speed   1000r/min
YB3-80M1-6 0.37 1.3 885 73.5 0.71 1.9 6 2.0
YB3-80M2-6 0.55 1.8 885 77.2 0.73 1.9 6 2.1
YB3-90S-6 0.75 2.3 910 78.9 0.73 2 6 2.1
YB3-90L-6 1.1 3.2 910 81.0 0.74 2 6.5 2.1
YB3-100L-6 1.5 3.9 920 82.5 0.74 2 6.5 2.1
YB3-112M-6 2.2 5.6 935 84.3 0.74 2 6.6 2.1
YB3-132S-6 3 7.4 960 85.6 0.75 2 6.8 2.1
YB3-132M1-6 4 9.8 960 86.8 0.79 2 6.8 2.1
YB3-132M2-6 5.5 12.9 965 88.0 0.8 2 6.8 2.1
YB3-160M1-6 7.5 17.2 970 89.1 0.81 2 7.2 2.1
YB3-160L-6 11 24.2 970 90.3 0.81 2 7.2 2.1
YB3-180L-6 15 31.6 970 91.2 0.84 2 7.4 2.1
YB3-200L1-6 18.5 38.6 980 91.7 0.85 2 6.9 2.1
YB3-200L2-6 22 44.7 980 92.2 0.86 2 7.1 2.1
YB3-225M-6 30 59.3 980 92.9 0.85 2 7.3 2.1
YB3-250M-6 37 71.1 980 93.3 0.85 2 6.6 2.0
YB3-280S-6 45 85.9 980 93.7 0.86 2 6.7 2.0
YB3-280M-6 55 105 980 94.1 0.86 2 6.7 2.0
YB3-315S-6 75 142 985 94.6 0.87 2 6.7 2.0
YB3-315M-6 90 170 985 94.9 0.87 2 6.8 2.0
YB3-315L1-6 110 207 985 95.1 0.88 2 6.8 2.0
YB3-315L2-6 132 245 985 95.4 0.87 2 6.8 2.0
YB3-355M1-6 160 338 990 95.6 0.88 1.8 6.8 2.0
YB3-355M2-6 200 365 990 95.8 0.88 1.8 6.8 2.0
YB3-355L-6 250 455 990 95.8 0.88 1.8 6.8 2.0
Synchronous speed   750r/min
YB3-80M1-8 0.18 0.88 645 58.7 0.67 1.8 5.9 2.0
YB3-80M2-8 0.25 1.15 645 64.1 0.69 1.8 6.2 2.0
YB3-90S-8 0.37 1.49 670 69.3 0.7 1.8 6.7 2.0
YB3-90L-8 0.55 2.17 670 73.0 0.71 1.8 6.7 2.0
YB3-100L1-8 0.75 2.4 680 75.0 0.73 1.8 6.7 2.0
YB3-100L2-8 1.1 3.4 680 77.7 0.74 1.8 6.9 2.0
YB3-112M-8 1.5 4.4 690 79.7 0.74 1.8 6.9 2.0
YB3-132S2-8 2.2 6 705 81.9 0.75 1.8 6.9 2.0
YB3-132M1-8 3 7.9 705 83.5 0.76 1.8 6.6 2.0
YB3-160M1-8 4 10.3 720 84.8 0.78 1.9 6.6 2.0
YB3-160M2-8 5.5 13.6 720 86.2 0.79 1.9 6.8 2.0
YB3-160L-8 7.5 17.8 720 87.3 0.79 1.9 6.8 2.0
YB3-180L-8 11 25.1 730 88.6 0.81 2 7 2.0
YB3-200L-8 15 34.1 730 89.6 0.81 1.9 6.7 2.0
YB3-225S-8 18.5 41.1 730 90.1 0.82 1.9 6.7 2.0
YB3-250M-8 22 47.4 730 90.6 0.82 1.9 6.8 2.0
YB3-280S-8 30 63.4 730 91.3 0.83 1.8 6.3 2.0
YB3-280M-8 37 77.8 740 91.8 0.87 1.8 6.4 2.0
YB3-315S-8 45 94.1 735 92.2 0.86 1.8 6.4 2.0
YB3-315M-8 55 111 735 92.5 0.86 1.8 6.4 2.0
YB3-315L1-8 75 151 735 93.1 0.86 1.8 6.4 2.0
YB3-315L2-8 90 178 735 93.4 0.87 1.8 6.4 2.0
YB3-355M1-8 110 217 735 93.7 0.88 1.8 6.4 2.0
YB3-355M2-8 132 261 740 94.3 0.88 1.8 6.4 2.0
YB3-355L-8 160 315 740 94.6 0.88 1.8 6.4 2.0
Type Power
kW
Current
A
Speed
r/min
Eff
%
Power factor Locked rotor torque
Rated torque
Locked rotor current
Rated current
Breakdown torque
Rated torque
Synchronous speed    600r/min
YB3-315S-10 45 99.6 590 92.0 0.75 1.5 6 2
YB3-315M-10 55 121 590 92.0 0.75 1.5 6.1 2
YB3-315L-10 75 162 590 92.8 0.76 1.3 6.1 2
YB3-355M1-10 90 230 590 93.0 0.78 1.3 6.1 2
YB3-355M2-10 110 275 590 93.3 0.78 1.3 6.1 2
YB3-355L-10 132 333 590 93.8 0.78 1.3 6.1 2

TAG:

YB3 series Explosion-Proof Three-Phase Induction Motor
+
  • YB3 series Explosion-Proof Three-Phase Induction Motor

YB3 series Explosion-Proof Three-Phase Induction Motor


Product application areas: ldeal for the coal mine where methane and coal. Dust may be present(Ex d I)and dangerous explosion areas (Exd Ⅱ AT4、dⅡBT4) in the plant with the class, and temperature T1~T4 flammable gas. Product features: All ratings Class I、Class II A &II B and Group T4,Cast iron conduit-box with three or six terminals for rubber jacket cable and steel conduit entry. Ambient temperature : -15℃~35℃ in coal mine and -15℃~40℃ in plant. Rated voltage: 380V, 660V, 380/660V
